Product Introduction
ATUS P2 Series Fixed Displacement External Gear Pump is a high-pressure heavy-duty gear pump engineered for mobile and industrial hydraulic systems. Adopting high-precision hard-faced gear pair and axial & radial pressure compensation structure, it maintains high volumetric efficiency under long-time high-pressure working conditions. The high-strength aluminum alloy housing delivers light weight and compact outline. Multiple displacement versions, single pump and multi-stage tandem options are available, standard interchangeable dimensions for direct replacement of mainstream brand pumps.
Technical Specifications:
Size NG: P2060 / P2075 / P2105 / P2145
Displacement(cm³): 60 / 75 / 105 / 145
Speed(rpm): 2800 / 2500 / 2300 / 2200
Flow (L/min) : 168 / 187.5 / 241.5 / 319
N.W.(KG): 37 / 44 / 63 / 78
Rated Pressure: 320 bar
Reak Pressure: 370 bar
Application Field: Hydraulic systems used on special vehicles, involving oil field equipment, mining equipment, and industrial handling
Features
External meshing gear structure with pressure compensation design for high efficiency
High-precision hardened alloy gear, low flow pulsation and smooth operation
High-strength aluminum alloy body, lightweight and good heat dissipation
Composite bearing bush, strong wear resistance for continuous high-speed operation
Wide displacement range, single pump, double pump and triple pump combinations optional
SAE standard flange and port configuration, abundant shaft selections
Bidirectional rotation available upon request
Optional high-pressure shaft seal for harsh working media
Low noise profile with optimized gear tooth profile
Full factory pressure and leakage inspection before shipment
Advantages
Stable high-pressure performance, less internal leakage after long running hours
Compact structure, easy installation in narrow chassis space
Strong contamination tolerance, suitable for dusty construction sites
Modular tandem design, one drive can supply multiple independent circuits
Simple internal structure, low failure rate and convenient field service
Wide working temperature range, adaptable to different climate zones
Flexible port orientation to match pipeline layout
Multiple seal options (NBR / FKM) for hydraulic oil, bio-oil
Cost-effective alternative to original pumps with short lead time
Rich inventory of common displacement models for fast delivery
Mounting Method
Standard SAE flange mounting; shaft options include straight key shaft, spline shaft and tapered shaft.
Rear interface supports tandem assembly for multi-pump combination.
Horizontal and vertical installation are both permitted, oil ports can be rotated to fit piping arrangement.
Application Range
Road sweepers, sanitation trucks, agricultural harvesters, forklifts, aerial work platforms, small construction machinery, material handling equipment, forestry machinery and general industrial hydraulic power units.
Notes & Service
Please confirm displacement, pump combination (single/tandem), shaft type, rotation direction and seal material before ordering.
ATUS P2 series gear pumps support modular assembly and field maintenance.
We provide professional technical support and reliable after-sales service.
FAQ
Q1: How to verify more realistically that ATUS is a factory?
A1: 1)Welcome to visite ATUS workshop by online video Live.
2)Field visite to ATUS manufacturing workshop
Q2: What is the MOQ ?
A2: MOQ 1 PCS
Q3: Can I mark my own brand on the pump?
A3: Sure. Full order Can mark your brand and code
Q4: How long is your delivery time ?
A4: 1).ATUS warehouse stock 2-3 days. No stock 7-15 days
2).ATUS custom production 7-10 days.
3).Mass production: determined according to the quantity
Q5: What payment method is accepted ?
A5: TT,LC,Western union,Trade assurance,VISA
Q6: How to Place your order ?
A6: 1).Tell us Model number ,quantity and other special requirements.
2).Proforma Invoice will be made and send for your approval.
3).Productions will be arranged upon receipt of your approval and payment or deposit.
4).Goods will be delivered as stated on the proforma invoice.
Q7: What kind of inspection you can provide ?
A7: 1).ISO9000 quality system certification.
2).ATUS is tested from material procurement to finished product by different departments such as QA, QC, and sales representatives to ensure that all pumps are in perfect condition prior to shipment. We also accept inspection by a third party you specify.
