Product Introduction
ATUS JR Series orbital hydraulic motor is a compact geroler low-speed high-torque motor, optimized for light and medium duty hydraulic drive systems. It features advanced roller gerotor design for higher efficiency and longer service life. Wide displacement range, abundant shaft, flange and port options support direct interchange for mainstream orbital motors, widely used in mobile and industrial auxiliary drives.
Technical Specifications:
Size NG: J45B / J51B / J60B / J65C / J75C
Displacement(cm³): 45 / 51 / 60 / 65 / 75
Speed(rpm): 2900 / 2700 / 2600 / 2500 / 2400
Flow (L/min) : 126 / 137.7 / 156 / 162.6 / 180
N.W.(KG): 23.1
Rated Pressure: 310 / 260 bar
Reak Pressure: 400 / 350bar
Application Field: Used in agriculture machinery, sanitation vehicles, etc., such as: harvesters, mowers, tractors, sweepers...
Features
Roller gerotor gear set design, lower friction loss and higher volumetric efficiency
Stable low-speed high-torque output, smooth rotation with minimal pulsation
Compact body structure, light weight and space-saving layout
Multiple shaft options: straight key shaft, splined shaft and tapered shaft
Various SAE flange, oval flange and port configuration selections
Bi-directional rotation available for forward and reverse control
Optional built-in relief valve and anti-cavitation check valve
Good anti-shock performance, adapts to frequent load fluctuation
Compatible with standard mineral hydraulic oil, wide temperature range
Interchangeable mounting dimensions for easy replacement
Product Advantages
Superior starting efficiency, excellent low-speed anti-crawling performance
Roller supported rotor group, greatly reduce wear under continuous operation
Modular construction, flexible configuration to match different equipment
Cost-effective import substitution with short delivery cycle
Simple disassembly and convenient on-site maintenance
Reliable sealing system, stable leakage control for long-term operation
Strong pollution resistance, suitable for dusty construction and farm sites
Optional FKM seals for high-temperature and special medium conditions
Flexible mounting orientation, horizontal and vertical installation supported
Every unit passes 100% pressure testing before shipment
Mounting Method
Standard 2-bolt / 4-bolt SAE flange mounting; optional oval flange.
Available with keyed, splined or tapered output shaft.
Can be installed on wheel hubs, gearboxes and equipment frames.
Keep coaxial alignment between output shaft and coupling to avoid excessive radial and axial load.
Mounting base needs sufficient rigidity to prevent vibration under pressure impact.
Application Range
Widely applied in sweepers, lawn mowers, harvesters, feed mixers, small conveyors, augers, winches, rotary tillers and other agricultural, sanitation and light construction machinery.
Notes & Service
Please confirm displacement, shaft type, mounting flange, port arrangement and rotation direction before ordering.ATUS JR orbital motors support modular assembly and field maintenance.We provide professional technical support and reliable after-sales service.
