Technical Data:
• Frame Sizes (NG): 40 / 60 / 75 / 95 / 130 / 145 / 190 / 260
• Displacement Range: 42 cc / 58.5 cc / 74 cc / 93.5 cc / 130 cc / 145 cc / 193 cc / 260 cc
• Nominal Pressure: 350 bar
• Peak Pressure: 400 bar
• Circuit Type: Designed for open-loop hydraulic systems
• Application: Primarily used in mobile equipment and tunneling machines
Control Methods:
• Power control (with various options, externally adjustable during operation)
• Pressure control
• Hydraulic control (based on pilot pressure)
• Electrical control (with proportional solenoid valves)
• Various customizable control combinations
Features & Advantages:
• Output flow is directly proportional to drive speed and pump displacement.
• Stepless flow regulation can be achieved easily by adjusting the swashplate angle between qV max and qV min = 0.
• Excellent oil suction characteristics and low operating noise levels.
• 100% through-shaft driven capability, perfectly suitable for connecting additional gear pumps or axial piston pumps.
